Description

Cutting capacity in mild steel                     20ga.

• Maximum slitting width                      24”
• Minimum slitting width                         2”
• Feed direction right to left
• Slitting speed                                              90 FPM
• Horsepower                                                 1/3 HP
• Voltage                                                        115V
• Phase                                                           1 PH
• Shaft Dia                                                      1-1/4”
• Blades                                                          2 PC
• Weight                                                         215 lbs.
• Dimensions:                                                 19” tall, 40” wide, 39” long
